A trip into Kotlin Multiplatform Projects, Part 4

Damiano Giusti by Damiano Giusti

Almost seven years ago, I wrote a small series about Kotlin Multiplatform. Back then, in part 1, part 2 and part 3, I was playing with a toy BLE library, talking to a Xiaomi Mi Band, and later fetching a list of users with a simple REST call. It was exciting, but it was still a playground. The expect/actual mechanism felt magical and fragile at the same time, the Gradle plugin changed name between releases, and shipping something to a real iOS app was more of a promise than a reality.

Fast forward to today. I now work at Empatica, on a medical-grade health monitoring app that runs on both Android and iOS, talks to real wearable devices, moves data to and from the backend, and does all of this from a shared Kotlin codebase. The toy grew up. And I think it deserves a fourth part.

What changed in almost seven years #

The first thing worth saying is that Kotlin Multiplatform is not experimental anymore. In 2019 I had to reassure the reader (and myself) that this thing could actually work. Today I don’t need to convince anyone: KMP is stable, JetBrains ships it as a first-class product, and the tooling around it is boringly reliable. Boring is a compliment here.

A few concrete numbers from the codebase I work on every day:

  • Kotlin 2.2.21, with the K2 compiler
  • Coroutines 1.9.0 for the threading abstraction I was so excited about in part 3
  • Ktor 3.2.3 as the multiplatform HTTP client — remember the hand-rolled REST call from part 3? That whole problem is now a solved, cross-platform library.
  • kotlinx.serialization and kotlinx.datetime — around back then, but still experimental and something you adopted with a bit of faith; today they’re just part of the toolbox
  • Gradle 8.14.5 driving the whole thing

Back in part 3 I spent paragraphs explaining how to abstract over threading, and how to move JSON across the platform boundary by hand. Almost all of that is now handed to you by the ecosystem. The interesting problems moved somewhere else.

From “does it work” to “does it scale” #

In the old series, the hard question was can I share code at all? Today, the hard question is how do I share code across many modules without the build collapsing under its own weight?

The shared layer I work on is a single Kotlin Multiplatform build made of several independent libraries — networking, persistence, domain logic — plus a handful of feature modules. Nothing exotic in principle: everything lives in commonMain as much as possible, and only drops into androidMain or iosMain when it truly has to touch the platform.

This is exactly the “framework-agnostic common module” principle I preached in part 1 — except now it’s load-bearing for a shipping product instead of a blog demo. It turns out the advice held up. What did not survive contact with reality was my assumption that, once the code was shared, the hard part was over. It wasn’t. The hard part was getting all of it into an iOS app cleanly.

The part nobody told me about in 2019: packaging #

Here’s the thing that the early tutorials (mine included) glossed over. Writing shared Kotlin is the easy part. Delivering that shared Kotlin to an iOS app is where the real work hides.

On Android there’s basically no drama — the KMP module produces a JAR/AAR and Gradle consumes it like any other dependency. iOS is the interesting side. Xcode doesn’t know what a Kotlin module is; it knows what an XCFramework is. So the shared world has to be packed into a binary artifact that Swift can import and call as if it were a native framework.

And here’s the problem that this whole section exists to explain.

The duplicate-class trap #

The setup I inherited did the intuitive thing, and then some: the shared code wasn’t just split into several modules — those modules lived in separate repositories, each one its own KMP project, each producing its own XCFramework. Clean, modular, every library versioned and shipped independently. It feels right. The iOS app imports all of them. It compiles.

Then the bugs start. A type produced by one framework can’t be passed into another. Swift complains that Foo is not Foo. The binary is mysteriously huge. Symbols look almost right but namespaced in a way nobody asked for.

Here’s what’s actually happening. When Kotlin/Native builds a framework, it statically links every Kotlin dependency into that framework and namespaces the symbols under it. So if five of your modules each depend on a common shared library, each framework carries its own private copy of that common library’s classes. In the host app you don’t get one SharedModel — you get ModuleA.SharedModel, ModuleB.SharedModel, ModuleC.SharedModel, all distinct Swift types that happen to share a name. Hand an object from one framework to another and the compiler is right to reject it: as far as it’s concerned, those are different types.

The fix was to stop shipping many frameworks. I pulled those modules out of their separate repositories and converged every one of them into a single Gradle project, then added an umbrella Gradle module whose only job is to export one XCFramework for the whole shared layer. Because everything now lives in one compilation, the common library gets linked exactly once: one canonical version of every type, one binary to version, one thing to sign, and one import on the Swift side. The umbrella module looks, in Gradle terms, roughly like this:

import org.jetbrains.kotlin.gradle.plugin.mpp.apple.XCFramework

val iosFrameworkName = "SharedMultiplatform"

// every shared module - example names
val sharedModules = listOf(
    ":networking",
    ":persistence",
    ":domain",
    // ...
)

kotlin {
    androidTarget()

    val xcf = XCFramework(iosFrameworkName)

    listOf(
        iosArm64(),           // real devices
        iosSimulatorArm64(),  // Apple Silicon simulators
    ).forEach { target ->
        target.binaries.framework {
            baseName = iosFrameworkName
            xcf.add(this)
        }
    }

    sourceSets.commonMain.dependencies {
        // pull every module into the umbrella
        sharedModules.forEach { api(project(it)) }
    }
}

That sharedModules list is the whole trick. Every library that used to be its own repository and its own framework is now just an entry here, folded into one compilation with a forEach. Adding a module to the shared layer means adding a line, not spinning up another framework. And because they all build together, the common code underneath them is linked exactly once.

Two more things about this snippet are worth pausing on.

First, notice the targets: iosArm64 for real devices and iosSimulatorArm64 for the simulator. In 2019 I was building for iosX64, because every Mac was Intel. That target still exists — but on Apple Silicon there’s simply no reason to build for it anymore.

JetBrains revised the targets DSL (the hierarchical source-set model), so declaring and combining targets is cleaner than the fiddly setup I fought with back then. Same capability, a much better way to express it. That’s the ecosystem maturing under your feet.

Second, the XCFramework helper. This didn’t exist in the old plugin. You used to assemble a fat framework by hand with a shell script full of lipo calls. Now it’s one Gradle type.

Getting the binary into the iOS app #

The framework has to reach the iOS app as a prebuilt, versioned artifact — no cloning the shared repo, no Kotlin toolchain, no Gradle. So the build zips the assembled XCFramework:

tasks.register<Zip>("zipXCFramework") {
    dependsOn("assemble${iosFrameworkName}XCFramework")
    archiveFileName.set("$iosFrameworkName-$version.zip")
}

To distribute it we lean on a tool the iOS world already knows: Carthage. It’s happy distributing a prebuilt binary XCFramework, so it fetches the versioned zip, unpacks the framework, and Swift imports it like any normal dependency. The Kotlin layer ends up looking like any other binary dep — which is the entire point. The best shared module is the one your platform teammates forget is written in Kotlin.

This is the path we took, and it works — but it isn’t free. The obvious cost is debuggability. A prebuilt binary is a black box: an iOS engineer who steps into the shared layer hits a compiled framework, not Kotlin source. When something misbehaves inside the shared code, you’re debugging across a boundary you can’t see through, and the tight edit-run-inspect loop that makes native development pleasant just isn’t there.

There’s another path that fixes exactly this: pull iOS, Android, and the KMP layer into a single monorepo and wire the shared code in as a source dependency the iOS project builds itself, instead of a binary it downloads. Now Xcode can step straight into the Kotlin, changes to the shared layer show up without republishing an artifact, and there’s one version of everything because there’s one repository. It’s not a free lunch either — it drags the Kotlin toolchain into every iOS engineer’s machine and makes the build heavier — but if debuggability and a single source of truth matter more than keeping the two worlds cleanly separated, it’s the trade I’d reach for next. (That migration is a whole story of its own, and probably another post.)

What I got right, and what I got wrong #

Reading my 2019 self is a fun exercise. Some things aged beautifully:

  • “Be framework-agnostic in the common module.” Still the single most important rule. Every time someone leaks a platform type into commonMain, they pay for it later.
  • “Use coroutines to abstract over threading.” More true than ever. Structured concurrency wasn’t even a term yet, and now it’s the backbone of every client we ship.

And some things were naïve:

  • I treated packaging and distribution as an afterthought. In a real product it’s half the effort.
  • I underestimated build times and IDE experience at scale. When you have this many modules, the question of how a single IDE indexes the whole thing — Android app, shared KMP, platform SDKs — becomes a real engineering topic on its own. (That’s probably its own blog post.)
  • I thought the risky part was Kotlin/Native. In practice, Kotlin/Native has been the stable part. The risky parts were all the boundaries: build configuration, versioning, and the Swift interop surface.

Cool, isn’t it? (still) #

In part 1 I asked “Cool, isn’t it?” about a demo that discovered Bluetooth devices. I’m asking the same question now, except the answer ships in an app that people wear on their wrist and depend on.

Kotlin Multiplatform delivered on the promise I was excited about in 2019 — one codebase, real Android, real iOS, no lowest-common-denominator compromise. It just delivered it quietly, by becoming ordinary. The magic didn’t disappear; it turned into infrastructure.

But I want to end this part on a more open question, because I think the why of code sharing is about to shift under us.

We share code because writing the same logic twice, in two languages, and keeping the two versions in sync by hand is expensive and error-prone. That’s the whole economic argument for KMP: one source of truth beats two drifting copies. But look at what AI tooling is starting to do. If a model can take a piece of Kotlin business logic and produce a faithful Swift translation — and, more importantly, keep it in parity as the Kotlin evolves — then “one shared binary” stops being the only way to get “one behavior on both platforms.”

I’m not saying KMP goes away. A single compiled source of truth has guarantees that a generated translation doesn’t — you can’t accidentally let the two drift, and you’re not trusting a model to be correct on every edge case. But the trade-off changes. Some of the pain I described in this post — the packaging, the interop surface, the binary you have to version and sign — exists precisely because we insist on shipping one artifact to two runtimes. If code parity becomes something you can get out-of-the-box from tooling, the honest question becomes: for which modules is a shared binary still worth its cost, and for which is idiomatic-per-platform code, kept in parity automatically, the better deal?

That’s the tension I want to explore next. Seven years ago the exciting question was “can we share code across platforms?” The answer turned out to be yes. The 2026 question is “given that we can, and given what AI now does — when should we?”

See you in part 5.

Written by me and my AI assistant :)
